Platinum 10 with SensO2 10-Liter Concentrator

HomeCatalogOxygen ConcentratorsPlatinum 10 with SensO2 10-Liter Concentrator

From Invacare

Platinum 10 with SensO2 10-Liter Concentrator
Platinum 10 with SensO2 10-Liter Concentrator thumbnail
×
1 / 1
Platinum 10 with SensO2 10-Liter Concentrator

Platinum 10 with SensO2 10-Liter Concentrator thumbnail

The Platinum 10 delivers the reliability, performance and value advantage you have come to expect from the Platinum line of concentrators and provides an attractive alternative to liquid systems.  The unit is available at up to 10 LPM for high-flow patients,  View more

  • In Stock

The Platinum 10 delivers the reliability, performance and value advantage you have come to expect from the Platinum line of concentrators and provides an attractive alternative to liquid systems.  The unit is available at up to 10 LPM for high-flow patients, and has less than 10 parts different from the Platinum XL 5-Liter concentrators, so making the transition is simple.  Fitzsimmons offers the Platinum 10 with Invacare's SensO2 oxygen purity sensor.

Features:
  • Spring-mounted compressor, easy access to service by removing only four cabinet screws, a top handle, and a side-access door for both the inlet filter and diagnostic
  • Features SensO2 oxygen purity sensor and is fully compatible with the HomeFill II transfilling system
  • Designed on the same platform as Platinum XL 5-liter concentrator
  • 3 Year Limited Warranty

For additional product information, including a larger picture of the unit, a more detailed description of added features, and advanced technical specifications, click on the Product Detail PDF located below, under the Additional Resources tab.

Oxygen output concentration levels 94% to 87% (at all flow rates)
Maximum outlet pressure 5+/- 0.5 psi
Flow range 2-10 LPM
Pressure relief mechanism operational 35 psi +/-3.5 psi
Dimensions 18 3/8" x 26 3/8" x 14 3/8"
Product Weight 54 lbs.
Electrical Requirements 120 VAC +/-10% (132 VAC/108 VAC) 60 Hz
Rated Current Input 4.9 A
Average power consumption 585 W
Sound level 58 dB average
